Trading bands, which are
lines plotted in and around the price structure to form an
envelope, are the action of prices near the edges of the
envelope that we are interested in. They are one of the
most powerful concepts available to the technically based
investor, but they do not, as is commonly believed, give
absolute buy and sell signals based on price touching the
bands. What they do is answer the perennial question of
whether prices are high or low on a relative basis. Armed with
this information, an intelligent investor can make buy and
sell decisions by using indicators to confirm price action.

But before we begin, we need a definition of what we are dealing with. Trading bands are lines plotted in and around the price structure to form an "envelope." It is the action of prices near the edges of the envelope that we are particularly interested in. The earliest reference to trading bands I have come across in technical literature is in*The Profit Magic of Stock
Transaction Timing*; author J.M. Hurst's approach involved
the drawing of smoothed envelopes around price to aid in cycle
identification.

Figure 1 shows an example of this technique: Note in particular the use of different envelopes for cycles of differing lengths.

The next major development in the idea of trading bands came in the mid to late 1970s, as the concept of shifting a moving average up and down by a certain number of points or a fixed percentage to obtain an envelope around price gained popularity, an approach that is still employed by many. A good example appears in Figure 2, where an envelope has been constructed around the Dow Jones Industrial Average (DJIA). The average used is a 21-day simple moving average. The bands are shifted up and down by 4%.

FIGURE 2:

The procedure to create such a chart is straightforward. First, calculate and plot the desired average. Then calculate the upper band by multiplying the average by 1 plus the chosen percent (1 + 0.04 = 1.04). Next, calculate the lower band by multiplying the average by the difference between 1 and the chosen percent (1 - 0.04 = 0.96). Finally, plot the two bands. For the DJIA, the two most popular averages are the 20- and 21-day averages and the most popular percentages are in the 3.5 to 4.0 range.

But before we begin, we need a definition of what we are dealing with. Trading bands are lines plotted in and around the price structure to form an "envelope." It is the action of prices near the edges of the envelope that we are particularly interested in. The earliest reference to trading bands I have come across in technical literature is in

Figure 1 shows an example of this technique: Note in particular the use of different envelopes for cycles of differing lengths.

The next major development in the idea of trading bands came in the mid to late 1970s, as the concept of shifting a moving average up and down by a certain number of points or a fixed percentage to obtain an envelope around price gained popularity, an approach that is still employed by many. A good example appears in Figure 2, where an envelope has been constructed around the Dow Jones Industrial Average (DJIA). The average used is a 21-day simple moving average. The bands are shifted up and down by 4%.

FIGURE 2:

The procedure to create such a chart is straightforward. First, calculate and plot the desired average. Then calculate the upper band by multiplying the average by 1 plus the chosen percent (1 + 0.04 = 1.04). Next, calculate the lower band by multiplying the average by the difference between 1 and the chosen percent (1 - 0.04 = 0.96). Finally, plot the two bands. For the DJIA, the two most popular averages are the 20- and 21-day averages and the most popular percentages are in the 3.5 to 4.0 range.

The next major innovation
came from Marc Chaikin of Bomar Securities who, in attempting
to find some way to have the market set the band widths rather
than the intuitive or random-choice approach used before,
suggested that the bands be constructed to contain a fixed
percentage of the data over the past year. Figure 3
depicts this powerful and still very useful approach. He stuck
with the 21-day average and suggested that the bands ought to
contain 85% of the data. Thus, the bands are shifted up
3% and down by 2%. Bomar bands were the result. The
width of the bands is different for the upper and lower bands.
In a sustained bull move, the upper band width will expand and
the lower band width will contract. The opposite holds true in
a bear market. Not only does the total band width change
across time, the displacement around the average changes as
well.

FIGURE 3:

FIGURE 3:

Asking the market what is
happening is always a better approach than telling the market
what to do. In the late 1970s, while trading warrants and
options and in the early 1980s, when index option trading
started, I focused on volatility as the key variable. To
volatility, then, I turned again to create my own approach to
trading bands. I tested any number of volatility measures
before selecting standard deviation as the method by which to
set band width. I became especially interested in standard
deviation because of its sensitivity to extreme deviations. As
a result, Bollinger Bands are extremely quick to react to
large moves in the market.

In Figure 5, Bollinger Bands are plotted two standard deviations above and below a 20-day simple moving average. The data used to calculate the standard deviation are the same data as those used for the simple moving average. In essence, you are using moving standard deviations to plot bands around a moving average. The time frame for the calculations is such that it is descriptive of the intermediate-term trend.

Note that many reversals occur near the bands and that the average provides support and resistance in many cases.

There is great value in considering different measures of price. The typical price, (high + low + close)/3, is one such measure that I have found to be useful. The weighted close, (high + low + close + close)/4, is another. To maintain clarity, I will confine my discussion of trading bands to the use of closing prices for the construction of bands. My primary focus is on the intermediate term, but short- and long-term applications work just as well. Focusing on the intermediate trend gives one recourse to the short- and long-term arenas for reference, an invaluable concept.

For the stock market and individual stocks. a 20-day period is optimal for calculating Bollinger Bands. It is descriptive of the intermediate-term trend and has achieved wide acceptance. The short-term trend seems well served by the 10-day calculations and the long-term trend by 50-day calculations.

The average that is selected should be descriptive of the chosen time frame. This is almost always a different average length than the one that proves most useful for crossover buys and sells. The easiest way to identify the proper average is to choose one that provides support to the correction of the first move up off a bottom. If the average is penetrated by the correction, then the average is too short. If, in turn, the correction falls short of the average, then the average is too long. An average that is correctly chosen will provide support far more often than it is broken. (See Figure 6.)

Bollinger Bands can be applied to virtually any market or security. For all markets and issues, I would use a 20-day calculation period as a starting point and only stray from it when the circumstances compel me to do so. As you lengthen the number of periods involved, you need to increase the number of standard deviations employed. At 50 periods, two and a tenth standard deviations are a good selection, while at 10 periods one and a nine tenths do the job quite well.

In most cases, the nature of the periods is immaterial; all seem to respond to correctly specified Bollinger Bands. I have used them on monthly and quarterly data, and I know many traders apply them on an intraday basis.

In Figure 5, Bollinger Bands are plotted two standard deviations above and below a 20-day simple moving average. The data used to calculate the standard deviation are the same data as those used for the simple moving average. In essence, you are using moving standard deviations to plot bands around a moving average. The time frame for the calculations is such that it is descriptive of the intermediate-term trend.

Note that many reversals occur near the bands and that the average provides support and resistance in many cases.

There is great value in considering different measures of price. The typical price, (high + low + close)/3, is one such measure that I have found to be useful. The weighted close, (high + low + close + close)/4, is another. To maintain clarity, I will confine my discussion of trading bands to the use of closing prices for the construction of bands. My primary focus is on the intermediate term, but short- and long-term applications work just as well. Focusing on the intermediate trend gives one recourse to the short- and long-term arenas for reference, an invaluable concept.

For the stock market and individual stocks. a 20-day period is optimal for calculating Bollinger Bands. It is descriptive of the intermediate-term trend and has achieved wide acceptance. The short-term trend seems well served by the 10-day calculations and the long-term trend by 50-day calculations.

The average that is selected should be descriptive of the chosen time frame. This is almost always a different average length than the one that proves most useful for crossover buys and sells. The easiest way to identify the proper average is to choose one that provides support to the correction of the first move up off a bottom. If the average is penetrated by the correction, then the average is too short. If, in turn, the correction falls short of the average, then the average is too long. An average that is correctly chosen will provide support far more often than it is broken. (See Figure 6.)

Bollinger Bands can be applied to virtually any market or security. For all markets and issues, I would use a 20-day calculation period as a starting point and only stray from it when the circumstances compel me to do so. As you lengthen the number of periods involved, you need to increase the number of standard deviations employed. At 50 periods, two and a tenth standard deviations are a good selection, while at 10 periods one and a nine tenths do the job quite well.

50 periods with 2.1 standard deviation | 10 periods with 1.9 standard deviation |

Upper Band
= 50-day SMA + 2.1(s) Middle Band = 50-day SMA Lower Band = 50-day SMA - 2.1(s) |
Upper Band
= 10-day SMA + 1.9(s) Middle Band = 10-day SMA Lower Band = 10-day SMA - 1.9(s) |

In most cases, the nature of the periods is immaterial; all seem to respond to correctly specified Bollinger Bands. I have used them on monthly and quarterly data, and I know many traders apply them on an intraday basis.

Trading bands answer the question whether prices are high or low on a relative basis. The matter actually centers on the phrase "a relative basis."

Some older work stated that deviation from a trend as measured by standard deviation from a moving average was used to determine extreme overbought and oversold states. But I recommend the use of trading bands as the generation of buy, sell and continuation signals through the comparison of an additional indicator to the action of price within the bands.

If price tags the upper band and indicator action confirms it, no sell signal is generated. On the other hand, if price tags the upper band and indicator action does not confirm (that is, it diverges). we have a sell signal. The first situation is not a sell signal; instead, it is a continuation signal if a buy signal was in effect.

It is also possible to generate signals from price action within the bands alone. A top (chart formation) formed outside the bands followed by a second top inside the bands constitutes a sell signal. There is no requirement for the second top's position relative to the first top, only relative to the bands. This often helps in spotting tops where the second push goes to a nominal new high. Of course, the converse is true for lows.

An indicator derived from Bollinger Bands that I call %b can be of great help, using the same formula that George Lane used for stochastics. The indicator %b tells us where we are within the bands. Unlike stochastics, which are bounded by 0 and 100, %b can assume negative values and values above 100 when prices are outside of the bands. At 100 we are at the upper band, at 0 we are at the lower band. Above 100 we are above the upper bands and below 0 we are below the lower band.

%b =

close - lower band

upper band - lower band

Indicator %b lets us compare price action to indicator action. On a big push down, suppose we get to -20 for %b and 35 for relative strength index (RSI). On the next push down to slightly lower price levels (after a rally), %b only falls to 10, while RSI stops at 40. We get a buy signal caused by price action within the bands. (The first low came outside of the bands, while the second low was made inside the bands.) The buy signal is confirmed by RSI, as it did not make a new low, thus giving us a confirmed buy signal.

Bandwidth =

upper band - lower band

middle band

Trading bands and indicators are both good tools, but when they are combined, the resultant approach to the markets becomes powerful. Bandwidth, another indicator derived from Bollinger Bands, may also interest traders. It is the width of the bands expressed as a percent of the moving average. When the bands narrow drastically, a sharp expansion in volatility usually occurs in the very near future. For example, a drop in band width below 2% for the Standard & Poor's 500 has led to spectacular moves. The market most often starts off in the wrong direction after the bands tighten prior to really getting under way, of which January 1991 is a good example.

A cardinal rule for the successful use of technical analysis requires avoiding multicollinearity amid indicators. multicollinearity is simply the multiple counting of the same information. The use of four different indicators all derived from the same series of closing prices to confirm each other is a perfect example.

So one indicator derived from closing prices, another from volume and the last from price range would provide a useful group of indicators. But combining RSI, moving average convergence/divergence (MACD) and rate of change (assuming all were derived from closing prices and used similar time spans) would not. Here are, however, three indicators to use with bands to generate buys and sells without running into problems. Amid indicators derived from price alone, RSI is a good choice. Closing prices and volume combine to produce on-balance volume, another good choice. Finally, price range and volume combine to produce money flow, again a good choice. None is too highly colinear and thus together combine for a good grouping of technical tools. Many others could have been chosen as well: MACD could be substituted for RSI, for example.

The Commodity Channel Index (CCI) was an early choice to use with the bands, but as it turned out, it was a poor one, as it tends to be colinear with the bands themselves in certain time frames. The bottom line is to compare price action within the bands to the action of an indicator you know well. For confirmation of signals, you can then compare the action of another indicator, as long as it is not colinear with the first.

Bollinger Bands were created by John Bollinger, CFA, CMT and published in 1983. They were developed in an effort to create fully-adaptive trading bands. The following rules covering the use of Bollinger Bands were gleaned from the questions users have asked most often and our experience over 25 years with Bollinger Bands.

*One of the great joys of having invented an analytical technique such as Bollinger Bands is seeing what other people do with it. These rules covering the use of Bollinger Bands were assembled in response to questions often asked by users and our experience over 25 years of using the bands. While there are many ways to use Bollinger Bands, these rules should serve as a good beginning point.*

To learn more about Bollinger Bands:

Bollinger on Bollinger Bands book

Introduction to Bollinger Bands DVD Covers essentials of how to use Bollinger Bands

Bollinger on Bollinger Bands 2013 Seminar Covers latest work

To view a webinar covering these 22 rules, click 22 Rules for Using Bollinger Bands.

© Bollinger Capital Management. All rights reserved.

- Bollinger Bands provide a relative definition of high and low. By definition price is high at the upper band and low at the lower band.
- That relative definition can be used to compare price action and indicator action to arrive at rigorous buy and sell decisions.
- Appropriate indicators can be derived from momentum, volume, sentiment, open interest, inter-market data, etc.
- If more than one indicator is used the indicators should not be directly related to one another. For example, a momentum indicator might complement a volume indicator successfully, but two momentum indicators aren't better than one.
- Bollinger Bands can be used in pattern recognition to define/clarify pure price patterns such as "M" tops and "W" bottoms, momentum shifts, etc.
- Tags of the bands are just that, tags not signals. A tag of the upper Bollinger Band is NOT in-and-of-itself a sell signal. A tag of the lower Bollinger Band is NOT in-and-of-itself a buy signal.
- In trending markets price can, and does, walk up the upper Bollinger Band and down the lower Bollinger Band.
- Closes outside the Bollinger Bands are initially continuation signals, not reversal signals. (This has been the basis for many successful volatility breakout systems.)
- The default parameters of 20 periods for the moving average and standard deviation calculations, and two standard deviations for the width of the bands are just that, defaults. The actual parameters needed for any given market/task may be different.
- The average deployed as the middle Bollinger Band should not be the best one for crossovers. Rather, it should be descriptive of the intermediate-term trend.
- For consistent price containment: If the average is lengthened the number of standard deviations needs to be increased; from 2 at 20 periods, to 2.1 at 50 periods. Likewise, if the average is shortened the number of standard deviations should be reduced; from 2 at 20 periods, to 1.9 at 10 periods.
- Traditional Bollinger Bands are based upon a simple moving average. This is because a simple average is used in the standard deviation calculation and we wish to be logically consistent.
- Exponential Bollinger Bands eliminate sudden changes in the width of the bands caused by large price changes exiting the back of the calculation window. Exponential averages must be used for BOTH the middle band and in the calculation of standard deviation.
- Make no statistical assumptions based on the use of the standard deviation calculation in the construction of the bands. The distribution of security prices is non-normal and the typical sample size in most deployments of Bollinger Bands is too small for statistical significance. (In practice we typically find 90%, not 95%, of the data inside Bollinger Bands with the default parameters)
- %b tells us where we are in relation to the Bollinger Bands. The position within the bands is calculated using an adaptation of the formula for Stochastics
- %b has many uses; among the more important are identification of divergences, pattern recognition and the coding of trading systems using Bollinger Bands.
- Indicators can be normalized with %b, eliminating fixed thresholds in the process. To do this plot 50-period or longer Bollinger Bands on an indicator and then calculate %b of the indicator.
- BandWidth tells us how wide the Bollinger Bands are. The raw width is normalized using the middle band. Using the default parameters BandWidth is four times the coefficient of variation.
- BandWidth has many uses. Its most popular use is to indentify "The Squeeze", but is also useful in identifying trend changes...
- Bollinger Bands can be used on most financial time series, including equities, indices, foreign exchange, commodities, futures, options and bonds.
- Bollinger Bands can be used on bars of any length, 5 minutes, one hour, daily, weekly, etc. The key is that the bars must contain enough activity to give a robust picture of the price-formation mechanism at work.
- Bollinger Bands do not provide continuous advice; rather they help indentify setups where the odds may be in your favor.
